NEW QUESTION # 103
Refer to the exhibit. A network engineer configured the redistribute connected subnets route-map filtering command on R1 to redistribute connected interfaces to the OSPF process. The engineer also wants to filter out IP address 10.0.1.0/24, but the prefix still appears in the routing tables of the other routers on the network- Which action corrects the problem?
- A. Remove route-map sequence 30.
- B. Change the deny statement in access list 2 to permit
- C. Remove the subnets keyword from the redistribute connected subnets route-map filtering command.
- D. Add a set statement to route-map sequence 20.
Answer: B
NEW QUESTION # 104
Refer to the exhibit.
A network operator must inject a Level 1 route from XR2 (10.16.16.0/24) into the ISIS topology. Which configuration allows the injection in a way that XR3 and XR1 have a valid and working route for 10.16.16.0/24?
- A. Option A
- B. Option C
- C. Option D
- D. Option B
Answer: B
NEW QUESTION # 105
Refer to the exhibit.
Refer to the exhibit Networks 172.16.31.0/24 and 172 16 30.0/24 are advertised in area 34. and network 172.22 10.0/24 is advertised in area 0. A recent security review discovered that users connected to routers R1 and R2 have been making unauthorized access to an application running on network 172 16 31 0/24 An engineer determined that routers R1 and R2 are receiving updates for network 17 16 31 0/24 Which action resolves the issue?
- A. Apply route filtering on routers RI and R2
- B. Apply route filtering on router R4 only.
- C. Apply route filtering on router R3 only.
- D. Apply route filtering on routers R3 and R4.
Answer: B
NEW QUESTION # 106
Which command is used to enable BIDIR-PIM under global configuration mode for Cisco IOS XE Sofware?
- A. ip multicast-routing
- B. ipv4 pim bidir-enable
- C. ip pim bidir
- D. ip pim bidir-enable
Answer: D
Explanation:
https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/ipmulti_pim/configuration/xe-3s/imc-pim-xe-
3sbook/imc_basic_cfg.html
NEW QUESTION # 107
Referring to the topology diagram show in the exhibit, which three statements are correct regarding the BGP routing updates? (Choose three.)
- A. The IBGP routing updates received by R2 from R1 will be propagated to the R3 router
- B. The EBGP routing updates received by R1 from R5 will be propagated to the R2, R4, and R7 routers
- C. The EBGP routing updates received by R3 from R6 will be propagated to the R2 and R4 routers
- D. The EBGP routing updates received by R1 from R5 will be propagated to the R2 and R4 routers
- E. The IBGP routing updates received by R1 from R4 will be propagated to the R5, R7, and R2 routers
- F. The IBGP routing updates received by R3 from R2 will be propagated to the R6 router
Answer: B,C,F
NEW QUESTION # 108
Refer to the exhibit. A network engineer applied configuration on R5 to summarize all OSPF routes, but R4 is still receiving specific routes from R5. The engineer has confirmed that both R5 and R4 routers are configured with correct summarization configuration but R5 Is not sending the summary routes. What action must the engineer take to fix the problem?
- A. Move R4 and R5 in separate areas as now they maintain the same link-state database
- B. Clear link-state database on both R4 and R5 routers for summarization to work
- C. Configure a sham link between R4 and R5 to support summarization within Area 2
- D. Remove summarization configuration on R5 and configure it on R4
Answer: A
NEW QUESTION # 109
Refer to the exhibit.
An administrator is troubleshooting Internet access issues on a customer's network. After applying this ISIS configuration to R1, the administrator notices that it fails to redistribute the default route into IS-IS. After checking the connectivity between the ISIS router and the ISP router the engineer confirmed there is Layer 3 connectivity between them Which action should be taken to correct the problem?
- A. Add the default-information originate command to the configuration
- B. Configure the default route under any routing protocol other than IS-IS
- C. Configure R1 as a Layer 1 router
- D. Associate the default route with a VRF
Answer: A
NEW QUESTION # 110
Refer to the exhibit. A network engineer commissioned Router 1, which connects to Router 2 and Router 5. Router 1 participates in IS-1S routing with other routers, but it is not used for transit traffic. Traffic from Router 2 to Router 5 is expected to travel via Router 1, but the traffic is travelling via Router 3 and Router 4. Which action resolves this problem?
- A. Remove the overload bit on Router 1.
- B. Remove the hello padding on Router 5.
- C. Add hello padding on Router 1
- D. Add the overload bit on Router 5.
Answer: A
NEW QUESTION # 111
Refer to the exhibit.
A network engineer has divided AS into confederations. Due to repeated ASN, when the 10.0 0.0/8 prefix from R1 arrives to R2, BGP automatically rejects it. What should the engineer do to fix the problem so that BGP allows that prefix on R2?
- A. Configure the command as-override on R1.
- B. Configure the command allowas-in on all the PE routers.
- C. Configure the command as-override on R2.
- D. Configure the command allowas-in on R2.
Answer: D
NEW QUESTION # 112
Refer to the exhibit. A network operator is working to deploy a Unified BGP design and allow it to be available only in selected markets and services in the future. The label allocation is not functioning as desired. Which action will fix the issue?
- A. Reconfigure the route-policy ALL_LABELS to pass.
- B. Remove the route policy and only configure "allocate-label".
- C. Remove the allocate-labels command.
- D. Reconfigure the route-policy ALL_LABELS to match all after the drop.
Answer: A
NEW QUESTION # 113
Refer to the exhibit.
Refer to the exhibit. Network connectivity between bank A and bank B has been lost Users at bank A and bank B are able to successfully reach their directly connected PE routers. All routers in OSPF area 0 are correctly advertising and learning routing updates. Which action resolves the issue?
- A. Enable next-hop-self under the iBGP peering configuration on routers PEI and PE2
- B. Configure the P routers to redtstnbute BGP routes within OSPF area 0.
- C. Configure router PI to advertise the IP prefix of PEI.
- D. Configure MPLS with an end-to-end label-switched path on each router.
Answer: D
NEW QUESTION # 114
Refer to the exhibit. While configuring router 2 with all the default values, a network engineer cannot see any route received in router 1. How should the engineer solve the issue?
- A. Modify the IP address or mask of the interface to a valid one.
- B. Set up a priority different than 0 in the interface.
- C. Modify the router ID to be the interface IP on the serial.
- D. Set the network type in S1/0 to point-to-point.
Answer: A
NEW QUESTION # 115
Refer to the exhibit.
Router 1 and Router2 have shared routes in the OSPF database but the routes are missing from their routing tables. Checking me prefix-list configuration on both routers, the engineer confirmed all networks are allowed What action should the engineer take to fa the problem?
- A. Configure interface Senal1/0 on Router1 as a point-to-point interface
- B. Configure the two routers with different process IDs
- C. Switch the DR and BDR roles between the two routers
- D. Configure the two routers with different hello and dead timer values
Answer: A
NEW QUESTION # 116
Refer to the exhibit. A network operator is working to deploy a Unified BGP design and allow it to be available only in selected markets and services in the future. The label allocation is not functioning as desired. Which action will fix the issue?
- A. Reconfigure the route-policy ALL_LABELS to pass.
- B. Remove the route policy and only configure "allocate-label".
- C. Remove the allocate-labels command.
- D. Reconfigure the route-policy ALL_LABELS to match all after the drop.
Answer: A
NEW QUESTION # 117
Refer to the exhibit. After creating dynamic neighbors for the range specified, the network administrator with an employee ID: 4698:80:283 cannot see all the BGP neighbors established.
What is the issue?
- A. A list of neighbors belongs only to a defined ASN.
- B. The listen limit is smaller than the prefix defined in the listen range.
- C. The single activated neighbor cannot be within the listen range.
- D. The peer groups must also be activated inside the address family.
Answer: D
NEW QUESTION # 118
Refer to the exhibit.
Refer to the exhibit. Mid-sized company Z connected two branch offices via a multicast-enabled ISP using the BGP routing protocol. PIM was implemented to support multicast streaming between the branches via MSDP Client A cannot connect to the multicast stream source of company Z. The network engineer ran a debug on the edge of the network as shown. Which action resolves the issue?
- A. Configure the PIM protocol on the Serial 1/1 interface and enable Auto-RP
- B. Deploy BSR on routers R1 and R2 and enable multicast on both LAN segments.
- C. Enable the BGP routing protocol and advertise the 10 10.10.0/24 subnet on R1.
- D. Implement MBGP and enable a multicast address family on R2
Answer: B
NEW QUESTION # 119
Refer to the exhibit. XR1 and XR2 are sending the prefix 10.11.11.0/24 to XR3. A configured policy on XR1 is incorrectly prepending AS path 11 11 12 12 onto this prefix. A network operator wants to add a policy onto XR3 that will not allow the falsely prepending prefix from being installed. Which policy configuration applied to the XR3 neighbor configuration for XR1 can accomplish this requirement without impact to other or future received routes?
- A.
- B.
- C.
- D.
Answer: B
Explanation:
Explanation/Reference: https://www.cisco.com/c/en/us/td/docs/routers/crs/software/crs_r4-1/routing/command/reference/ b_routing_cr41crs/b_routing_cr41crs_chapter_01000.html#wp3850885229
NEW QUESTION # 120
Which statement about BFD on Cisco IOS XR Software is true?
- A. Cisco IOS XR router must use LDP to route back to the Cisco IOS router to establish the peer relationship.
- B. Cisco IOS XR Software does not support BFD multihop for IPv4.
- C. Cisco IOS XR router must use dynamic routing or a static route back to the Cisco IOS router to establish the peer relationship.
- D. BFD is not compatible between Cisco IOS XR and Cisco IOS Software.
Answer: C
Explanation:
A router running BFD in Cisco IOS software can designate a router running BFD in Cisco IOS XR software as its peer using the bfd neighbor command; the Cisco IOS XR router must use dynamic routing or a static route back to the Cisco IOS router to establish the peer relationship. https://www.cisco.com/c/en/us/td/docs/routers/crs/software/crs_r6-1/routing/configuration/guide/b-routing-cg-crs-61x/b-routing-cg-crs-61x_chapter_0100.html Reference:
guide/b-routing-cg-asr9000-63x/b-routing-cg-asr9000-63x_chapter_0100.html
NEW QUESTION # 121
Refer to the exhibit. A network engineer must optimize link failures on the OSPF routing domain.
The solution must follow RFC 5286, and downtime must be no more than 50 ms. All known subnets on R1 must be protected. Which solution must the engineer implement on R1?
- A. Configure fast-reroute per-prefix enable prefix-priority low under the global OSPF configuration.
- B. Configure frr per-prefix enable priority high under the global OSPF configuration.
- C. Configure ip ospf frr per-prefix candidate enable high under the interface configuration
- D. Configure ip ospf fast-reroute per-prefix candidate enable under the interface configuration.
Answer: A
NEW QUESTION # 122
Which keyword is used with the match route-type command to redistribute the external BGP and IGP routes using route map?
- A. match route-type external
- B. match route-type type-2
- C. match route-type nssa-external
- D. match route-type type-1
Answer: A
Explanation:
https://www.cisco.com/c/en/us/support/docs/ip/border-gateway-protocol-bgp/49111-route-map- bestp.html
NEW QUESTION # 123
Refer to the exhibit.
Refer to the exhibit. This network is deployed with all connected links configured to run IS-IS. The routing protocol is enacted globally on each router, and the network engineer expects full routing Information to be shared among all routers. R5 is receiving routes from R4 but is missing routes from R1. Which action corrects the issue so that all routes are shared among the routers?
- A. Configure R3 as a Level 2 we.
- B. Configure R5 in the same as RI,
- C. Configure all routers to reside in toe area.
- D. Configure RI and RS as Level 1"Level 2
Answer: C
NEW QUESTION # 124
Level 3 switch SW1 is part of an EIGRP enabled network located at the edge of an area. Cisco Express Forwarding and SSO are enabled on the router. A network engineer must minimize the downtime of data-transmit services in the network. HSRP group 2 has already been configured with standby preempt delay minimum 2 and standby timers 140.
Which additional action must the engineer take on SW1 to suppress routing flaps for 2 minutes?
- A. Configure timers nsf route-hold 120 under the global EIGRP configuration.
- B. Configure timers nsf signal 2 under the global EIGRP IPv4 address family.
- C. Configure timers standby 2 wait 2 under the HSRP group 2 configuration.
- D. Configure timers standby 2 coverage 120 under the HSRP group 2 configuration.
Answer: A
NEW QUESTION # 125
Refer to the exhibit
An engineer is configuring service traffic from router R1 to R6 as shown. Which additional configuration must the engineer implement so that the LDP and SR domains will participate and interwork with each other?
- A. Router2(config)# segment-routing
Router2(config-sr)# ldp mapping-server
Router2(config-sr-ms)# prefix-sid-map
Router2(config-sr-ms-map)# address-family ipv4
Router2(config-sr-ms-map-af)# 2.2.2.2/32 500 range 40 - B. Router2(config)# segment-routing
Router2(config-sr)# sr mapping-server
Router2(config-sr-ms)# ldp-sid-map
Router2(config-sr-ms-map)# address-family ipv4
Router2(config-sr-ms-map-af)# 10.1.1.1/32 500 range 50 - C. Router2(config)# segment-routing
Router2(config-sr)# ldp mapping-server
Router2(config-sr-ms)# prefix-sid-map
Router2(config-sr-ms-map)#
Router2(config-sr-ms-map-af)# 2.2.2.2/32 500 range 4 - D. Router2(config)# segment-routing
Router2(config-sr)# mapping-server
Router2(config-sr-ms)# prefix-sid-map
Router2(config-sr-ms-map)# address-family ipv4
Router2(config-sr-ms-map-af)# 10.1.1.1/32 500 range 50
Answer: D
NEW QUESTION # 126
Refer to the exhibit.
Refer to the exhibit. A network engineer is configuring router R3 to handle multicast streams, but Host-2 cannot send subscriptions messages to the IPTV source. Which configuration must the engineer apply to router R3 so it passes the IPTV stream to Host-2?
- A. Option C
- B. Option A
- C. Option D
- D. Option B
Answer: C
NEW QUESTION # 127
What are two characteristics of BGP confederations? (Choose two.)
- A. Intra-Confederation EBGP neighbors must be directly connected or ebgp-multihop must be configured.
- B. All routers within the BGP confederation must support BGP confederations.
- C. An Intra-Confederation EBGP session behaves like an EBGP session when propagating routing updates.
- D. The member AS numbers used within the confederation are visible from outside the confederation.
Answer: A,B
NEW QUESTION # 128
......
